Pressure Transmitter PBT-CB1X0SGTSEFALA0Z | -1 to 0 Bar Range | 4-20mA Output | IP65 Rated | by SICK
The PBT-CB1X0SGTSEFALA0Z Pressure Transmitter is designed for accurate compound pressure measurement from -1 bar to 0 bar, making it ideal for industrial process control. With a robust stainless steel 316L housing and an IP65 rating, it ensures durability in harsh environments. This sensor features a fast response time under 4 ms and an output signal of 4 mA to 20 mA, perfect for monitoring liquid and gaseous media pressure.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: -1 bar to 0 bar
- Process temperature range: -30 °C to +100 °C
- Output signal: 4 mA to 20 mA, 2-wire
- Supply voltage: 8 V DC to 30 V DC
- Accuracy: ≤ ±1% of span
- Response time: < 4 ms
- Enclosure rating: IP65
- Material: Stainless steel 316L housing and wetted parts
- Connection type: L-connector (DIN EN 175301-803 A)
- Overvoltage protection: 36 V DC
- Shock load resistance: 500 g
- Vibration load resistance: 10 g (20 g optional)
- Dimensions (H x L x W): 70mm x 70mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures compound pressure from -1 bar to 0 bar
- Output signal: 4 mA to 20 mA, 2-wire
- Process connection: G ½ A (ISO 1179-2)
- Housing and wetted parts made of stainless steel 316L
- Overvoltage protection up to 36 V DC
- IP65 rated enclosure for dust and water protection
- High accuracy with ≤ ±1% of span
- Fast response time under 4 ms
- Long service life with minimum 100 million load cycles
- Shock and vibration resistant
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Measurement of liquid and gaseous media pressure
- Industrial process control requiring compound pressure measurement
- Use in environments with temperatures from -30°C to +100°C
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel construction reduces waste and replacement frequency
- Low power consumption enhances energy efficiency
- Long service life minimizes environmental impact from disposal
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK PBT-CB1X0SGTSEFALA0Z Pressure Sensor is available for immediate purchase, ideal for industrial and process control applications requiring precise compound pressure measurement.
