Pressure Transmitter PBT-CB1X1SGTESFAMA0Z | -1 to 1 Bar Range | IP67 Rated | 4-20mA Output | by SICK
The PBT-CB1X1SGTESFAMA0Z Pressure Transmitter is designed for accurate measurement of liquid and gaseous media pressure, featuring a compound pressure range of -1 to 1 bar. With a robust stainless steel housing and IP67 enclosure rating, it ensures durability in industrial environments. Ideal for process control applications, this sensor offers a fast response time of less than 4 ms and high accuracy of ≤ ±1% of span.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Medium: Liquid, gaseous
- Pressure type: Compound pressure
- Measuring range: -1 bar to 1 bar
- Process temperature range: 0°C to +80°C
- Output signal: 4 mA to 20 mA, 2-wire
- Process connection: G ½ A (ISO 1179-2)
- Wetted parts: 316L stainless steel
- Housing material: Stainless steel
- Connection type: M12 round connector, 4-pin
- Supply voltage: 8 V DC to 30 V DC
- Power consumption: Max 25 mA for current output
- Electrical safety: Overvoltage protection 32-36 V DC, short-circuit and reverse polarity protection
- Enclosure rating: IP67
- Accuracy: ≤ ±1% of span
- Response time: < 4 ms
- Service life: Minimum 100 million load cycles
- Shock load: 500 g IEC 60068-2-27
- Vibration load: 10 g IEC 60068-2-6, 20 g optional
- Dimensions (H x L x W): 80mm x 50mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures compound pressure in the range of -1 bar to 1 bar
- Output signal: 4 mA to 20 mA, 2-wire
- Process connection: G ½ A (ISO 1179-2)
- Wetted parts made of 316L stainless steel for corrosion resistance
- Housing made of stainless steel with IP67 enclosure rating
- Overvoltage protection up to 36 V DC and short-circuit protection
- High accuracy with ≤ ±1% of span including non-linearity and hysteresis
- Fast response time of less than 4 ms
- Long service life with minimum 100 million load cycles
- Shock and vibration resistant according to IEC standards
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical safety standards.
Applications
- Measurement of liquid and gaseous media pressure
- Industrial process control requiring compound pressure measurement
- Environments with process temperatures from 0°C to 80°C
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel construction reduces replacement frequency and waste
- Low power consumption enhances energy efficiency in industrial applications
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK PBT-CB1X1SGTESFAMA0Z Pressure Sensor is available for immediate purchase, ideal for industrial and process control applications requiring precise compound pressure measurement.
