Pressure Transmitter PBT-CB4X0SGTSSNAMA0Z | -1 to 3 Bar Range | IP67 Rated | High Accuracy | by SICK
The Pressure Transmitter PBT-CB4X0SGTSSNAMA0Z measures compound pressure from -1 bar to 3 bar, making it ideal for industrial process control of liquid and gaseous media. With a robust stainless steel 316L construction and an IP67 rated enclosure, it ensures durability and reliability in demanding environments. Experience high accuracy with a response time under 4 ms, perfect for manufacturing and automation systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: -1 bar to 3 bar
- Process temperature range: 0 °C to +80 °C
- Output signal: 4 mA to 20 mA, 2-wire
- Supply voltage: 8 V DC to 30 V DC
- Pressure connection: G ½ A (ISO 1179-2)
- Wetted parts: Stainless steel 316L
- Enclosure rating: IP67
- Electrical safety: Overvoltage protection 32-36 V DC, short-circuit and reverse polarity protection
- Accuracy: ≤ ±1% of span including non-linearity, hysteresis, zero point and full scale error
- Response time: < 4 ms
- Shock load resistance: 500 g
- Vibration resistance: 10 g standard, 20 g optional
- Dimensions (H x L x W): 70mm x 30mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures compound pressure from -1 bar to 3 bar
- Suitable for liquid and gaseous media
- Stainless steel 316L wetted parts and housing for durability
- Output signal: 4 mA to 20 mA, 2-wire
- High accuracy with ≤ ±1% span including non-linearity and hysteresis
- Fast response time under 4 ms
- IP67 rated enclosure for protection against dust and water
- Overvoltage, short-circuit, and reverse polarity protection
- M12 round 4-pin connector for easy electrical connection
- Long service life with minimum 100 million load cycles
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial process control for liquid and gaseous media
- Pressure monitoring in manufacturing and automation systems
- Use in environments requiring compound pressure measurement
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel construction reduces replacement frequency and waste
- Low power consumption enhances energy efficiency in industrial applications
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK PBT-CB4X0SGTSSNAMA0Z pressure sensor is available for immediate purchase, ideal for industrial and process control applications.
