Pressure Transmitter PBT-CB6X0AG2SS0VMC0Z | Compound Pressure Measurement | IP67 Rated | 0-10V Output | by SICK
The Pressure Transmitter PBT-CB6X0AG2SS0VMC0Z is designed for accurate compound pressure measurement of liquids and gases, with a measuring range from -1 bar to 5 bar. Built for industrial process control, it features a robust stainless steel housing and an IP67 enclosure rating, ensuring durability in demanding environments. With a fast response time under 4 ms and high accuracy of ≤ ±0.5% of span, this sensor is perfect for reliable pressure monitoring in various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Medium: Liquid, gaseous
- Pressure type: Compound pressure
- Measuring range: -1 bar to 5 bar
- Process temperature range: 0 °C to +80 °C
- Output signal: 0 V to 10 V, 3-wire
- Process connection: G ¼ female (EN 837)
- Wetted parts: 316L stainless steel
- Housing material: Stainless steel
- Connection type: M12 round connector, 4-pin
- Supply voltage: 14 V DC to 30 V DC
- Power consumption: Max 25 mA for current output, max 8 mA for voltage output
- Electrical safety: Overvoltage protection 32 V DC, short-circuit and reverse polarity protection
- Enclosure rating: IP67
- Accuracy: ≤ ±0.5% of span
- Response time: < 4 ms
- Service life: Minimum 100 million load cycles
- Shock load: 500 g according to IEC 60068-2-27
- Vibration load: 10 g according to IEC 60068-2-6
- Dimensions (H x L x W): 70mm x 30mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures compound pressure from -1 bar to 5 bar
- Output signal: 0 V to 10 V, 3-wire
- Process connection: G ¼ female (EN 837)
- Wetted parts made of 316L stainless steel
- Housing made of stainless steel with IP67 enclosure rating
- Overvoltage, short-circuit, and reverse polarity protection
- High accuracy with ≤ ±0.5% of span
- Fast response time under 4 ms
- Long service life with minimum 100 million load cycles
- Shock and vibration resistant according to IEC standards
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical safety standards.
Applications
- Measurement of liquid and gaseous media pressure
- Industrial process control requiring compound pressure measurement
- Use in environments with temperatures from 0°C to 80°C
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel housing ensures long product life reducing waste
- Low power consumption minimizes energy use
- High accuracy reduces process errors and material waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK PBT-CB6X0AG2SS0VMC0Z Pressure Sensor is available for immediate purchase, ideal for industrial and process control applications requiring reliable pressure measurement.
