Pressure Transmitter PTAC-1XXXXC3AFMZB | Gauge Pressure Sensor | Bluetooth Enabled | IP66, IP67, IP69 | by SICK
The Pressure Transmitter PTAC-1XXXXC3AFMZB is designed for precise gauge pressure measurement in liquid and gaseous media. With a measuring range of 0 to 5 bar and a durable ceramic pressure measuring cell, it ensures high accuracy and fast response times. Ideal for industrial process control, this sensor features Bluetooth communication for easy configuration and robust stainless steel housing for enhanced protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Medium: Liquid, gaseous
- Pressure type: Gauge pressure
- Pressure unit: bar, psi
- Measuring chamber type: Ceramic pressure measuring cell
- Measuring range: 0 bar to 5 bar (0 psi to 72 psi)
- Process temperature: –20 °C to +130 °C
- Maximum ohmic load RA: RA < (L+ - 12) / 0.022 A (Ohm)
- Output signal: 4 mA to 20 mA, 2-wire
- Communication interface: Bluetooth
- Process connection: G ½ (ISO 228-1)
- Wetted parts: 316L stainless steel
- Housing material: Stainless steel 316L (1.4404), PBT/PC
- Connection type: M12 round connector, 4-pin
- Supply voltage: 12 V DC to 35 V DC
- Electrical safety: Overvoltage protection 36 V DC, short-circuit resistance, reverse polarity protection
- Dielectric strength: 500 V AC, NEC Class 02 power supply
- Enclosure rating: IP66, IP67, IP69
- Accuracy: ≤ ± 0.3 % of span
- Response time (10% to 90%): ≤ 6 ms
- Long-term drift: < 0.1 % per annum
- Temperature coefficient: < 0.15% per 10 K
- Rated temperature range: 0 °C to +100 °C
- Service life: Minimum 10 million load cycles
- Ambient temperature operation: –40 °C to +80 °C
- Storage temperature: –40 °C to +80 °C
- Shock load: Class 6M4 IEC60721-3-6 (50 g; 2.3 ms)
- Vibration load: Class 4M8 IEC60721-3-4 (5 g, 4 Hz to 200 Hz)
- Dimensions (H x L x W): 100mm x 50mm x 50mm
- Weight: 0.25 kg
Key Features
- Measures gauge pressure in liquid and gaseous media
- Ceramic pressure measuring cell for durability and precision
- Measuring range from 0 bar to 5 bar (0 psi to 72 psi)
- Process temperature range from –20 °C to +130 °C
- Output signal: 4 mA to 20 mA, 2-wire
- Bluetooth communication interface for easy configuration
- Process connection: G ½ (ISO 228-1) with 316L stainless steel wetted parts
- Housing made of stainless steel 316L and PBT/PC for robust protection
- Electrical safety features including overvoltage protection, short-circuit resistance, and reverse polarity protection
- Enclosure rated IP66, IP67, and IP69 for high ingress protection
- High accuracy of ≤ ± 0.3 % of span and fast response time ≤ 6 ms
- Long-term stability with less than 0.1 % drift per annum
- Shock and vibration resistant according to IEC standards
- Protection class III and compliance with multiple international certifications
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper connection, calibration, and compliance with safety standards.
Applications
- Measurement of liquid and gaseous media pressure
- Industrial process control requiring gauge pressure monitoring
- Environments requiring high accuracy and fast response pressure sensors
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Durable stainless steel and ceramic construction reduces waste and extends product life
- Low power consumption with efficient 4-20 mA output signal
- Bluetooth interface enables wireless configuration reducing need for physical adjustments and associated resource use
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK PTAC-1XXXXC3AFMZB Pressure Sensor is available for immediate purchase, ideal for industrial and process control applications requiring precise pressure measurement.
