Pressure Transmitter PTAC-1XXXXC5ACMZB | Bluetooth Enabled | IP66/IP67/IP69 Rated | High Accuracy | by SICK
The Pressure Transmitter PTAC-1XXXXC5ACMZB is designed for precise gauge pressure measurement in industrial applications. With a measuring range of 0 bar to 0.4 bar and Bluetooth communication, it offers high accuracy of ≤ ± 0.3% of span. Built for durability with a robust stainless steel housing and IP66/IP67/IP69 ratings, this sensor is perfect for harsh environments and automation systems requiring reliable pressure monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: 0 bar to 0.4 bar (0 psi to 5.8 psi)
- Process temperature range: –20 °C to +130 °C
- Accuracy: ≤ ± 0.3% of span
- Response time: ≤ 6 ms
- Long-term drift: < 0.35% per annum
- Supply voltage: 12 V DC to 35 V DC
- Output signal: 4 mA to 20 mA, 2-wire
- Process connection: G 1 flush-mounted (ISO 228-1)
- Housing material: Stainless steel 316L (1.4404), PBT/PC
- Electrical safety: Overvoltage protection 36 V DC, short-circuit resistance, reverse polarity protection
- Enclosure rating: IP66, IP67, IP69
- Communication interface: Bluetooth
- Seal material: FKM
- Dielectric strength: 500 V AC
- Dimensions (H x L x W): 100mm x 50mm x 50mm
- Weight: 0.25 kg
Key Features
- Measures gauge pressure in liquid and gaseous media
- Ceramic pressure measuring cell for durability
- Bluetooth communication interface for easy data access
- Output signal: 4 mA to 20 mA, 2-wire
- High accuracy of ≤ ± 0.3% of span
- Wide process temperature range from –20 °C to +130 °C
- Robust stainless steel 316L housing and wetted parts
- Protection ratings IP66, IP67, and IP69 for harsh environments
- Overvoltage, short-circuit, and reverse polarity protection
- Long service life with minimum 10 million load cycles
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with pressure sensor integration and electrical safety standards.
Applications
- Industrial process control for liquid and gaseous media
- Pressure monitoring in manufacturing plants
- Automation systems requiring precise gauge pressure measurement
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable materials and long service life reduce waste and replacement frequency
- Low power consumption with efficient 2-wire output signal
- Bluetooth interface reduces wiring complexity and material use
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK PTAC-1XXXXC5ACMZB Pressure Sensor is available for immediate purchase, ideal for industrial and automation applications requiring precise pressure measurement.
