Proximity Sensor AS30-EBM314I110ZZZ | Web Guiding & Positioning | IP67 Rated | by SICK
The AS30-EBM314I110ZZZ proximity sensor excels in web guiding and positioning, featuring a sensing distance of up to 25 mm and a high resolution of 0.1 mm. Designed for industrial automation, it operates efficiently within -10 °C to +55 °C, ensuring reliable performance in demanding environments. With an IP67 rating and robust zinc diecast housing, this sensor is perfect for precision measurement and small object detection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor principle: Proximity system
- Functional principle: Web guiding, positioning
- Sensing distance: ≤ 25 mm
- Working range: 20 mm to 30 mm
- Measurement range: 30 mm
- Minimum detectable object: 0.2 mm
- Light source: LED, White
- Wavelength: 400 nm to 700 nm
- Light spot size: 39 mm x 12.2 mm
- Repeatability: 0.2 mm
- Linearity: ± 2%
- Resolution: 0.1 mm
- Adjustment: IO-Link, Display
- Teach-in mode: Edge detection, Area detection
- Supply voltage: 18 V to 30 V
- Current consumption: < 3.1 W
- Switching frequency: 500 Hz
- Switching output: Push-pull PNP/NPN
- Analog output: 4 mA to 20 mA, 12 bit resolution
- Output rate: 1 ms
- Output current max: < 100 mA
- Initialization time: 0.48 s
- Connection type: Male connector M12, 5-pin
- Protection class: III
- Circuit protection: Reverse polarity, short-circuit, interference pulse suppression
- Enclosure rating: IP67
- Housing material: Zinc diecast
- Optics material: Glass
- Operating temperature: -10 °C to +55 °C
- Storage temperature: -25 °C to +75 °C
- Dimensions (H x L x W): 62mm x 52mm x 31mm
- Weight: 0.25 kg
Key Features
- Proximity sensor with web guiding and positioning functionality
- Sensing distance up to 25 mm with working range 20 mm to 30 mm
- High resolution of 0.1 mm and repeatability of 0.2 mm
- LED white light source with wavelength 400 nm to 700 nm
- Push-pull PNP/NPN switching output and 4 mA to 20 mA analog output
- IO-Link communication interface for easy integration and adjustment
- Robust zinc diecast housing with IP67 protection rating
- Operating temperature range from -10 °C to +55 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connection and sensor alignment for optimal performance.
Applications
- Web guiding and positioning in industrial automation
- Precision measurement in manufacturing processes
- Detection of small objects with minimum size 0.2 mm
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient operation with low power consumption (<3.1 W)
- Durable zinc diecast housing reduces waste through long product life
- Complies with China-RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK AS30-EBM314I110ZZZ proximity sensor is available for immediate purchase, ideal for industrial automation and precision web guiding applications.
