Proximity Sensor AS30-EBM534I220C00 | Web Guiding & Positioning | IP67 Rated | by SICK
The AS30-EBM534I220C00 proximity sensor excels in web guiding and positioning applications, featuring a sensing distance of up to 100 mm and a high resolution of 1 µm. With its robust IP67 rated zinc diecast housing and LED white light source, this sensor is perfect for precision measurement in industrial automation, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensor principle: Proximity system, Reflector mode
- Functional principle: Web guiding, positioning
- Sensing distance: ≤ 100 mm
- Working range: 90 mm to 110 mm
- Measurement range: 30 mm
- Minimum detectable object: 0.5 mm
- Light source: LED, White (400 nm to 700 nm)
- Light spot size: 62.5 mm x 13.2 mm
- Repeatability: 0.05 mm
- Linearity: ± 2%
- Resolution: 1 µm
- Adjustment: IO-Link, Display
- Teach-in mode: Edge detection, Area detection
- Supply voltage: 18 V to 30 V
- Current consumption: < 3.1 W
- Switching frequency: 500 Hz
- Switching output: Push-pull PNP/NPN
- Analog output: 4 mA to 20 mA, 12 bit resolution
- Output rate: 1 ms
- Output current max: < 100 mA
- Connection type: Male connector M12, 5-pin
- Protection class: III
- Circuit protection: Reverse polarity, short-circuit, interference pulse suppression
- Enclosure rating: IP67
- Housing material: Zinc diecast
- Optics material: Anti-reflex coating
- Operating temperature: -10 °C to +55 °C
- Storage temperature: -25 °C to +75 °C
- Shock load: According to IEC 60068
- Dimensions (H x L x W): 62mm x 52mm x 31mm
- Weight: 0.25 kg
Key Features
- Proximity system with reflector mode
- Web guiding and positioning functional principle
- Sensing distance up to 100 mm
- High resolution of 1 µm and repeatability of 0.05 mm
- LED white light source with wavelength 400 nm to 700 nm
- IP67 rated zinc diecast housing with anti-reflex coating
- IO-Link communication interface for easy integration
- Push-pull PNP/NPN switching output and 4 mA to 20 mA analog output
- Operating temperature range from -10 °C to +55 °C
- Short initialization time of 0.48 seconds
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician familiar with industrial sensor systems and IO-Link communication protocols.
Applications
- Web guiding and positioning in industrial automation
- Precision measurement in manufacturing processes
- Object detection and edge detection in production lines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable zinc diecast housing extends product lifespan, reducing waste
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK AS30-EBM534I220C00 proximity sensor is available for immediate purchase, ideal for industrial automation and web guiding applications.
