Proximity Sensor IQ12-04BPOKW2S | IP68 Rated | 2000 Hz Switching Frequency | PNP Output | by SICK
The Proximity Sensor IQ12-04BPOKW2S is designed for industrial automation, featuring a high switching frequency of 2000 Hz and an IP68 enclosure rating for dust and water resistance. With a sensing range of 4 mm and robust design, it's perfect for object detection and safety monitoring in manufacturing and robotics applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Proximity Sensor IQ12-04BPOKW2S | IP68 Rated | 2000 Hz Switching Frequency | PNP Output | by SICK
Brand: SICK
SKU: 1055429
Alternatively Known As: Proximity Sensor IQ12, Flush Mount Proximity Sensor, Rectangular Inductive Sensor, SICK Proximity Switch
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Switching frequency: 2,000 Hz
- Switching output: PNP, NC function
- Connection type: Cable, 3-wire, 2 m length
- Enclosure rating: IP68
- Hysteresis: 5% to 15%
- Reproducibility: ≤ 2%
- Voltage drop: ≤ 2 V
- No load current: 10 mA
- Continuous current Ia: ≤ 200 mA
- Shock resistance: 30 g, 11 ms
- Vibration resistance: 10 to 55 Hz, 1 mm amplitude
- Operating temperature: -25 °C to +75 °C
- Housing material: Plastic, VISTAL®
- Cable material: PVC, diameter 3.7 mm
- Short-circuit and power-up pulse protection included
- Dimensions (H x L x W): 40mm x 26mm x 12mm
- Weight: 0.1 kg
Key Features
- Rectangular housing with flush installation
- Sensing range of 4 mm with safe sensing range of 3.24 mm
- High switching frequency of 2,000 Hz
- PNP switching output with NC function
- Cable connection, 3-wire, 2 m length
- Enclosure rating IP68 for dust and water resistance
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Short-circuit and power-up pulse protection included
- Wide operating temperature range from -25 °C to +75 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper flush mounting and electrical connection according to safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in machinery
- Robotics and assembly lines
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable IP68 rated housing reduces environmental damage and extends product life
- Low power consumption with efficient DC 3-wire electrical wiring
- Robust design minimizes waste through long service life
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK IQ12-04BPOKW2S proximity sensor is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
