Proximity Sensor MQ10-60ANSKT0 | IP67 Rated | 60mm Sensing Range | 1000Hz Switching Frequency | by SICK
The Proximity Sensor MQ10-60ANSKT0 is designed for industrial automation, featuring a sensing range of up to 60 mm and a high switching frequency of 1,000 Hz for rapid response. With an IP67 rated enclosure, it offers robust protection against dust and water, making it ideal for harsh environments. Perfect for manufacturing process control and safety monitoring, this sensor ensures reliable performance in various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 5 mA
- Switching output: NPN, normally open
- Switching frequency: 1,000 Hz
- Sensing range Sn: 0 mm to 60 mm
- Safe sensing range Sa: 48.6 mm
- Connection type: Connector M8, 3-pin
- Enclosure rating: IP67
- Voltage drop: ≤ 1.5 V
- Hysteresis: 1% to 10%
- Reproducibility: ≤ 1%
- Shock resistance: 30 g, 11 ms
- Vibration resistance: 10 to 55 Hz, 1 mm
- Operating temperature: -25°C to +75°C
- Housing material: Plastic, VISTAL®
- EMC compliant according to EN 60947-5-2
- Reverse polarity, short-circuit, and power-up pulse protection included
- Dimensions (H x L x W): 28mm x 16mm x 10mm
- Weight: 0.1 kg
Key Features
- Rectangular housing with compact dimensions
- Sensing range up to 60 mm with safe sensing range of 48.6 mm
- High switching frequency of 1,000 Hz for fast response
- NPN switching output with normally open function
- IP67 rated enclosure for dust and water protection
- Reverse polarity, short-circuit, and power-up pulse protection
- Shock and vibration resistant for harsh environments
- Wide operating temperature range from -25°C to +75°C
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper wiring and compliance with safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in machinery
- Robotics and conveyor systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Low power consumption of 5 mA supports energy efficiency
- Robust protection extends product life in harsh environments
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MQ10-60ANSKT0 proximity sensor is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
