PS Comp Ring Kit 25-30 mm | 660-1100V | 150A Current Rating | IP55 Protection by Ausproof
PS Comp Ring Kit 25-30 mm with 660-1100V voltage and 150A current rating—ideal for mining and tunnelling applications. Built for hazardous environments, with durable stainless steel construction and quick release features for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PS Comp Ring Kit 25 - 30 mm
Brand: Ausproof
SKU: RS2219
Alternatively Known As: PS Range Flameproof Plug Kit, Ex-certified Electrical Ring Kit, Mining Electrical Connector Kit
Technical Specifications
- Voltage: 660 to 1,100 V
- Current Rating: 150 A
- Material: Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 2 tests of 12.5kA for 0.2 seconds
- Through Fault Current (Earth): 2 tests of 4.0kA for 0.2 seconds
- AC High Voltage Withstand (Phase): 4.2kV for one minute
- AC High Voltage Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: 150A rating
- Compliant to: AS/NZS 1299, IEC 60079-0, IEC 60079-1
- Dimensions (H x L x W): 150mm x 150mm x 150mm
- Weight: 7.9 kg
Key Features
- Quick Release
- Single piece contacts to prevent hot joints
- Easy termination
- Easy flameproof repair
- Full solid earth connectivity throughout product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone Protection Cover
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Installation and maintenance should be performed by qualified electricians trained in hazardous area equipment to ensure safety and compliance.
Applications
- Mining
- Tunnelling
- Commercial applications
- Group 1 hazardous environments
Standards & Compliance
- Complies with AS/NZS 1299 for flameproof enclosures and electrical equipment in hazardous areas
Environmental Benefits
- Durable stainless steel construction reduces need for frequent replacements.
- Flameproof repairability reduces waste by allowing on-site repairs without full replacement.
Warranty Information
Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.
Available Now
The Ausproof PS Comp Ring Kit 25 - 30 mm is available now for immediate purchase. Ideal for mining, tunnelling, and commercial hazardous environment applications.
