Push Button 22.5mm Flush Heavy Duty 1NO 24VAC DC Allen-Bradley
Allen-Bradley illuminated push button featuring 22.5mm, 1NO, 24VAC DC, illuminated operator and flush mounting. Ideal for machine start, stop and reset control.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Voltage: 24V AC/DC
- Contact Configuration: 1 Normally Open (NO)
- Terminal Type: Stab terminals
- Color: Black body with green LED illumination
- Head Type: Flush
- Dimensions (H x L x W): 30mm x 50mm x 30mm
- Weight: 0.1 kg
Key Features
- Illuminated push button with green LED
- Flush head design for safety and aesthetics
- Full voltage operation
- Stab terminals for easy wiring
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and safety.
Applications
- Industrial control panels
- Machinery operation interfaces
- Automation systems requiring illuminated push buttons
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- LED illumination reduces energy consumption compared to traditional bulbs
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 800MBCQAL24GD1 Illuminated Push Button is discontinued by the manufacturer but available for immediate purchase through Radwell with a 2-year warranty. Ideal for industrial control panel applications.
