Push Button Head | Blue Flush Actuator | IP66 Rated | 22mm Diameter | by Clipsal
The Push Button Head is designed for reliable operation in industrial control panels, featuring a blue flush actuator and a push/push to release mechanism. With a robust plastic construction and IP66 rating, it's perfect for automation systems and machinery applications, ensuring durability and flexibility in high-frequency operations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Push Button Head | Blue Flush Actuator | IP66 Rated | 22mm Diameter | by Clipsal
Brand: Clipsal
SKU: SCHZB5AH06
Alternatively Known As: Push button head, push to release button, Clipsal ZB5AH06, 22mm pushbutton, blue flush actuator
Technical Specifications
- Actuator type: Push/push to release
- Head type: Flush
- Colour: Blue
- Mounting diameter: 22mm
- Material: Plastic
- Mechanical durability: 1,000,000 cycles
- Degree of protection: IP66 (front face)
- Operating temperature: -40°C to +70°C
- Dimensions (H x L x W): 29mm x 40mm x 29mm
- Weight: 0.1 kg
Key Features
- Blue flush pushbutton head
- Push/push to release mechanism
- Unmarked actuator for flexible use
- 22mm diameter mounting
- Robust plastic construction
- Suitable for high-frequency operation
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with safety standards and proper integration into control systems.
Applications
- Industrial control panels
- Machinery start/stop operations
- Automation systems
- Manufacturing equipment
- Electrical control stations
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable design reduces replacement frequency and waste
- RoHS compliant materials minimize environmental impact
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal ZB5AH06 Blue Flush Pushbutton Head is available for immediate purchase. Ideal for industrial control panels, automation, and machinery applications.
