PVC Cable Tray Cantilever Arm 300mm | Durable PVC Material | 750 N Safe Working Load | Halogen Free | @Each of 1 | by Cablofil
The PVC Cable Tray Cantilever Arm 300mm is designed for robust support in electrical installations, made from durable halogen-free PVC. With a safe working load of 750 N, it’s perfect for industrial and commercial cable management systems, ensuring secure mounting and compliance with standards. Ideal for use in environments requiring reliable cable support.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PVC Cable Tray Cantilever Arm 300mm | Durable PVC Material | 750 N Safe Working Load | Halogen Free | @Each of 1 | by Cablofil
Brand: Cablofil
SKU: 637769
Alternatively Known As: PVC Cable Tray Bracket, Cantilever Arm Support, Cable Tray Support Bracket, PVC Cable Tray Mounting Arm
Technical Specifications
- Material: Polyvinyl chloride (PVC)
- Length: 353 mm
- Width: 80 mm
- Height: 130 mm
- Suitable for cable support system width: 300 mm
- Safe working load: 750 N (IEC 61537)
- Operating temperature: -5°C to 60°C
- Storage temperature: -5°C to 60°C
- Surface protection: Other
- Halogen free: Yes
- Angle: 90°
- Dimensions (H x L x W): 130mm x 353mm x 80mm
- Weight: 0.3 kg
Key Features
- Made from durable polyvinyl chloride (PVC) material
- Halogen free for enhanced safety
- Safe working load of 750 N according to IEC 61537
- Suitable for cable support system width of 300 mm
- Operating temperature range from -5°C to 60°C
- Grey color with RAL number 7030
Professional Installation Requirements
- Professional installation by qualified personnel is recommended to ensure secure mounting and compliance with electrical and structural standards.
Applications
- Supports and fixes PVC cable trays in electrical installations
- Ideal for industrial, commercial, and infrastructure cable management systems
- Used in cable support systems requiring cantilever arm brackets
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Halogen-free material reduces harmful emissions in case of fire
- Durable PVC construction extends product lifespan, reducing waste
Warranty Information
Standard manufacturer warranty applies; please refer to Legrand for specific warranty details.
Available Now
Legrand PVC Cable Tray Cantilever Arm 300mm is available for immediate purchase, ideal for supporting PVC cable trays in commercial and industrial electrical installations.
