PVC Cable Tray Unperforated 100mm x 75mm | Durable PVC Material | Grey Color | @Each of 1 | by Cablofil
The PVC Cable Tray Unperforated 100mm x 75mm is designed for effective cable management in commercial and industrial settings. Made from durable polyvinyl chloride (PVC), it features an unperforated design for maximum cable protection and operates within a temperature range of -5°C to 60°C. Ideal for routing and protecting electrical cables indoors, this tray ensures compliance with electrical standards while providing a long service life.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PVC Cable Tray Unperforated 100mm x 75mm | Durable PVC Material | Grey Color | @Each of 1 | by Cablofil
Brand: Cablofil
SKU: 637810
Alternatively Known As: PVC Cable Tray, Cable Management Tray, Electrical Cable Tray, Unperforated Cable Tray
Technical Specifications
- Height: 75 mm
- Width: 100 mm
- Length: 3000 mm
- Material thickness: 2.3 mm
- Usable cross section: 6440 mm²
- Material: Polyvinyl chloride (PVC)
- Operating temperature: -5°C to 60°C
- Storage temperature: -20°C to 60°C
- Colour: Grey (RAL 7030)
- Surface protection: Untreated
- Halogen free: No
- No perforations on sides or bottom
- No cover included
- Dimensions (H x L x W): 75mm x 3000mm x 100mm
- Weight: 3.5 kg
Key Features
- Unperforated design for maximum cable protection
- Made from durable polyvinyl chloride (PVC)
- Grey color (RAL 7030) for standard industrial use
- Operating temperature range from -5°C to 60°C
- Material thickness of 2.3 mm for strength and durability
- Untreated surface with no halogen content
Professional Installation Requirements
- Installation should be performed by a qualified electrician or professional installer to ensure compliance with electrical standards and secure cable management.
Applications
- Cable management in commercial and industrial electrical installations
- Routing and protection of electrical cables in buildings
- Suitable for indoor use in dry environments
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- PVC material is recyclable and designed for long service life reducing replacement waste
- Non-halogenated material reduces harmful emissions in case of fire
Warranty Information
Standard manufacturer warranty applies; please refer to Legrand for specific warranty details.
Available Now
The Legrand PVC Cable Tray Unperforated 100mm x 75mm x 3m Length is available for immediate purchase, ideal for commercial and industrial electrical cable management applications.
