Quick Release Gland Bracket 3300V 425A | IP55 Rated | Stainless Steel | Ausproof

BRAND: Ausproof

SKU: RS2639QR

$3,839.00 List price: $4,768.00

+ −

30 Days Return Delivery Options

The Quick Release Gland Bracket offers a voltage range of 660V to 3300V and a current rating of 425A—ideal for mining and hazardous environments. Built for professional installation, it features a durable stainless steel design and IP55 ingress protection for reliable performance.

Description

Product Name/Title: PL QR 3300V 425A 6P Gland Bracket (0) 95-C 60-65-G (241.3)

Brand: Ausproof

SKU: RS2639QR

Alternatively Known As: PL Range Gland Bracket, Ex-rated Receptacle, Quick Release Gland Bracket, Mining Electrical Connector

Technical Specifications

Voltage Range: 660V to 3300V
Current Rating: 300A to 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Weight: 10.7 kg (Receptacle)
Dimensions (H x L x W): 200mm x 400mm x 300mm
Weight: 10.7 kg

Key Features

Quick Release mechanism
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Professional installation by qualified electricians trained in hazardous area electrical equipment is required to ensure safety and compliance.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres
Complies with IEC 60079-0
Complies with IEC 60079-1

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements
Flameproof repairable design minimizes waste by allowing on-site repairs

Warranty Information

Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.

Available Now

The Ausproof PL QR 3300V 425A 6P Gland Bracket is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications requiring robust and flameproof electrical connections.
