Rackmount UPS 1150VA | Line-Interactive | 6 C13 Outputs | 97% Efficiency | 1U by Eaton
Protect your critical IT infrastructure with this 1150VA rackmount UPS, featuring line-interactive topology and six C13 output receptacles. Ideal for data centers and server rooms, it offers 97% efficiency and user-replaceable batteries for reliable power backup.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Rackmount UPS 1150VA | Line-Interactive | 6 C13 Outputs | 97% Efficiency | 1U by Eaton
Brand: Eaton
SKU: 9210-5378
Alternatively Known As: Eaton 5P 1150VA UPS, Eaton 5P Rackmount UPS, Eaton 5P 770W UPS, Eaton 5P 1U UPS
Technical Specifications
- Power Capacity: 1150 VA / 770 W
- Input Connection: C14
- Output Receptacles: 6 x C13
- Input Voltage Range: 160-294 V (adjustable to 150-294 V)
- Output Voltage Range: 230 V (+6%/-10%)
- Output Frequency: 50/60 Hz
- Nominal Voltage: 230 V (selectable 200/208/220/230/240 V)
- Topology: Line-interactive
- Battery Type: Lead-acid maintenance-free, user replaceable
- Battery Quantity: 2
- Battery Rating: 12 V / 9 Ah
- Communication Ports: USB (HID compliant), Serial (RS232), Mini-terminal block
- Noise Level: <40 dB at 1 meter
- Operating Temperature Range: 0-90% non-condensing humidity
- Form Factor: 1U Rackmount (482.6 mm 19 inch device)
- Efficiency at Max Load: 97%
- Auto Shutdown Function: Yes
- Phase: Single phase input and output
- Dimensions (H x L x W): 43.2mm x 509mm x 438mm
- Weight: 14.64 kg
Key Features
- Line-interactive UPS topology for reliable power conditioning
- User replaceable lead-acid maintenance-free batteries
- Six C13 output receptacles for versatile connectivity
- Rack-mountable 1U form factor suitable for 19-inch racks
- Automatic battery test and deep discharge protection
- USB and serial communication ports for monitoring and management
- Optional communication card slot for expanded connectivity
- High efficiency of 97% at maximum load
- Low noise level under 40 dB at 1 meter
Professional Installation Requirements
- Professional installation by qualified technicians is recommended to ensure proper rack mounting, electrical connections, and configuration.
Applications
- Data centers and server rooms
- Network and telecommunications equipment
- Industrial and commercial IT infrastructure
- Critical power backup for sensitive electronics
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- High efficiency design reduces energy consumption and heat generation
- Maintenance-free lead-acid batteries minimize hazardous waste
- Automatic battery test extends battery life and reduces unnecessary replacements
Warranty Information
Standard manufacturer warranty applies; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton 5P 1150VA / 770W 1U Rackmount UPS with LCD is available now for immediate purchase. Ideal for protecting critical IT and network equipment in commercial and industrial environments.
