Rafter Bracket 780mm Single Arm | Hot Dip Galvanised Steel | Complies with NSW Standards | by Supplico
The Rafter Bracket 780mm Single Arm is engineered from hot dip galvanised steel, ensuring exceptional corrosion resistance and durability. Ideal for securing single phase aluminium aerial service lines, this bracket complies with NSW service and installation rules, making it perfect for both residential and commercial roofing applications. Professional installation is recommended for optimal safety and performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Rafter Bracket 780mm Single Arm | Hot Dip Galvanised Steel | Complies with NSW Standards | by Supplico
Brand: Supplico
SKU: RB5-1
Alternatively Known As: Single Arm Rafter Bracket, Galvanised Rafter Bracket, Aerial Service Line Bracket
Technical Specifications
- Material: Hot dip galvanised steel
- Length: 780 mm
- Weight: 8 kg
- Suitable for single phase aluminium aerial service lines
- Complies with NSW service and installation rules
- Dimensions (H x L x W): 100mm x 780mm x 100mm
- Weight: 8 kg
Key Features
- Hot dip galvanised for corrosion resistance.
- Engineered to meet NSW service and installation rules.
- Suitable for approximately 30m of aerial for single phase aluminium service lines.
- Designed to be fixed to rafters behind fascia boards and flashed around roofing penetrations.
- Must be bolted through hardwood of adequate strength behind the fascia board.
Professional Installation Requirements
- Installation must be performed by a qualified professional ensuring the bracket is bolted through hardwood of adequate strength behind the fascia board.
Applications
- Designed for fixing to rafters behind fascia boards in residential and commercial roofing.
- Suitable for single phase aluminium aerial service lines installation.
- Used in compliance with NSW service and installation rules for aerial service lines.
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Hot dip galvanising extends product life, reducing the need for replacements and waste.
Warranty Information
Warranty details not specified; typically covered under manufacturer’s standard warranty.
Available Now
The Supplico Rafter Bracket 780mm Single Arm RB5-1 is available for immediate purchase, ideal for secure aerial service line installations in residential and commercial buildings.
