Trade Discount 17%
Razor Advanced Recessed Exit Light | DALI Driver | Maintained Emergency Mode | 90 Min Duration | Black | by Ektor
The Razor Advanced Recessed Exit Light is designed for effective emergency exit signage in commercial buildings. Featuring a DALI driver and maintained emergency mode, it provides 90 minutes of illumination during power outages. With a sleek black finish and a viewing distance of 24 meters, this light is perfect for corridors and stairwells, ensuring safety and compliance with emergency lighting standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Recessed Emergency Exit Sign, DALI Exit Light, Maintained Emergency Exit Sign, LED Exit Sign, Emergency Exit Indicator
Technical Specifications
- IP Rating: IP20
- Input Voltage: 230Vac (-6%/+10%)
- Input Frequency: 50 Hz
- Maximum Wattage: 2 W to 2.6 W depending on model
- Standby Power: 1.7 W to 2.3 W depending on model
- Driver Type: DALI DT1 Emergency or Wireless IEC62386-104 with DT1
- Wiring: Re-wireable 5 pin terminal block
- Emergency Output Power: 350 mW to 650 mW
- Emergency Duration: 90 minutes
- Viewing Distance: 24 meters
- Decal Size: 300 x 150 mm
- Operating Temperature: 0 to 40 °C
- Product Design Life: 8 years
- Emergency Light Source Life: Up to 34 years (projected)
- Dimensions (H x L x W): 180mm x 80mm x 320mm
- Weight: 1.2 kg
Key Features
- Recessed installation type with polycarbonate body and PMMA diffuser
- DALI DT1 Emergency driver included with integrated driver
- Maintained emergency mode with 90 minutes emergency duration
- Supports emergency test and monitoring over DALI (IEC62386) and wireless IEC62386-104
- Viewing distance of 24 meters with decal size 300 x 150 mm
- Low standby power consumption (1.7W to 2.3W depending on model)
- Operating temperature range from 0 to 40 °C
- Product design life of 8 years with LED light source life projection up to 34 years
Professional Installation Requirements
- Professional installation by a qualified electrician is required to ensure correct wiring, DALI integration, and compliance with emergency lighting standards.
Applications
- Commercial buildings emergency exit signage
- Public facilities requiring maintained emergency lighting
- Recessed installation in corridors, stairwells, and exit routes
Standards & Compliance
- AS/NZS 60598.1 – Luminaires General Requirements
- AS 60598.2.22 – Emergency Lighting Luminaires
- AS/NZS 61347.1 – Lamp Control Gear General and Safety Requirements
- AS/NZS 61347.2.13 – Particular Requirements for Emergency Lighting
- AS CISPR 15 – Limits and Methods of Measurement of Radio Disturbance
- AS/NZS 2293.3 – Emergency Escape Lighting and Exit Signs
Environmental Benefits
- Energy-efficient LED technology reduces power consumption during normal and emergency operation
- Long product and LED life reduces waste and replacement frequency
- Low standby power consumption minimizes energy use when not in emergency mode
Warranty Information
6 years return to base warranty for commercial use.
Available Now
The Ektor Razor Advanced Recessed Exit Light is available for immediate purchase, ideal for commercial and public building emergency exit lighting applications.
