RCBO 10A 10KA 110V 100mA | 4 Module Width | C Curve Tripping | by Clipsal
The RCBO 10A 10KA 110V 100mA is a combined residual current device and miniature circuit breaker, perfect for residential and commercial electrical distribution. With a 4 module width and C curve tripping characteristic, it provides reliable protection against overloads, short circuits, and earth leakage faults, ensuring safety in various environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 10A 10KA 110V 100mA | 4 Module Width | C Curve Tripping | by Clipsal
Brand: Clipsal
SKU: SCHA9D19210
Alternatively Known As: RCBO 10A, Residual Current Breaker with Overcurrent, Earth Leakage Circuit Breaker, Clipsal SCHA9D19210, 10A RCBO 110V, 4 Module RCBO
Technical Specifications
- Rated current: 10A
- Breaking capacity: 10kA
- Rated voltage: 110V AC
- Earth leakage sensitivity: 100mA
- Number of poles: 2P
- Tripping curve: C
- Module width: 4M
- Residual current type: AC
- Conforms to IEC/EN 61009-1
- Dimensions (H x L x W): 85mm x 75mm x 72mm
- Weight: 0.45 kg
Key Features
- Combined residual current device (RCD) and miniature circuit breaker (MCB) in one unit
- Rated current: 10A
- Breaking capacity: 10kA
- Rated voltage: 110V AC
- Earth leakage sensitivity: 100mA
- 4 module width (4M)
- C curve tripping characteristic for general purpose protection
- 2 pole (2P) configuration
- Provides protection against overloads, short circuits, and earth leakage faults
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Residential and commercial electrical distribution boards
- Industrial switchboards
- Protection of lighting and power circuits
- Environments requiring earth leakage and overload protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Long service life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal RCBO 10A 10KA 110V 100mA 4M (SCHA9D19210) is available for immediate purchase. Ideal for use in residential, commercial, and industrial switchboards requiring reliable circuit and earth leakage protection.
