RCBO 16A 10KA 110V 100mA | 4M Width | C Curve Tripping | by Clipsal
The RCBO 16A 10KA 110V 100mA is a combined residual current device and miniature circuit breaker, perfect for protecting electrical circuits in commercial, industrial, and residential switchboards. With a 4M width for easy installation and a C curve tripping characteristic, it ensures reliable performance and safety in low voltage installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 16A 10KA 110V 100mA | 4M Width | C Curve Tripping | by Clipsal
Brand: Clipsal
SKU: SCHA9D19216
Alternatively Known As: RCBO 16A, Earth Leakage Circuit Breaker, Residual Current Breaker with Overcurrent, SCHA9D19216, Clipsal RCBO 16A 4M, 16A RCBO 110V
Technical Specifications
- Rated current: 16A
- Breaking capacity: 10kA
- Rated voltage: 110V AC
- Earth leakage sensitivity: 100mA
- Tripping curve: C
- Number of poles: 2
- Module width: 4M (72mm)
- Mounting: DIN rail
- Standards: IEC/EN 61009-1
- Dimensions (H x L x W): 85mm x 75mm x 72mm
- Weight: 0.45 kg
Key Features
- Combined residual current device (RCD) and miniature circuit breaker (MCB) in one unit
- Rated current: 16A
- Breaking capacity: 10kA
- Rated voltage: 110V AC
- Earth leakage sensitivity: 100mA
- 4 module width for easy installation in standard DIN rail enclosures
- C curve tripping characteristic for general purpose protection
- 2 pole (2P) configuration
- High reliability and robust construction
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial electrical distribution boards
- Residential switchboards requiring earth leakage protection
- Protection of lighting and power circuits in low voltage installations
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of electrical fires and personal injury
- Long operational life reduces replacement frequency and electronic waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal RCBO 16A 10KA 110V 100mA 4M (SCHA9D19216) is available for immediate purchase. Ideal for protecting electrical circuits in commercial, industrial, and residential switchboards.
