Trade Discount 17%
RCBO 16A 3 Pole + Neutral | 10kA Breaking Capacity | 30mA Sensitivity | A Type by Eltech
This RCBO features a 16A rated current and 3 pole plus neutral configuration—ideal for residential and commercial electrical distribution. Built for safety, it offers 30mA sensitivity and a 10kA breaking capacity, ensuring reliable circuit protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 16A 3 Pole + Neutral 10kA 30mA – A type
Brand: Eltech
SKU: RCBO301630AH
Alternatively Known As: Residual Current Breaker with Overcurrent Protection, 16A RCBO, 3 Pole RCBO, 30mA RCD breaker
Technical Specifications
- Rated Current: 16A
- Poles: 3 Pole + Neutral
- Residual Current Rating: 30mA
- Type: A (AC and pulsating DC detection)
- Breaking Capacity: 10kA
- Mounting: DIN rail
- Dimensions (H x L x W): 85mm x 70mm x 54mm
- Weight: 0.3 kg
Key Features
- 16 Ampere rated current
- 3 Pole plus Neutral configuration
- Residual Current Device (RCD) with 30mA sensitivity
- A type RCBO suitable for detecting AC and pulsating DC residual currents
- 10kA short circuit breaking capacity
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
- Residential electrical distribution boards
- Commercial power distribution and circuit protection
- Industrial electrical panels requiring RCBO protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Enhances electrical safety reducing risk of electrical fires and shocks
- Helps prevent electrical faults that can cause energy waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Eltech warranty policy for details.
Available Now
The Eltech RCBO 16A 3 Pole + Neutral 10kA 30mA – A type is available now for immediate purchase. Ideal for circuit protection in residential, commercial, and industrial electrical installations.
