RCBO 16A 6kA 240V 30mA | Type A | Trip-Free Mechanism | 2 Module Width | @Pack of 1 | by Clipsal
The RCBO 16A 6kA 240V 30mA is a Type A residual current circuit breaker that combines RCD and MCB functionalities in one unit. With a trip-free mechanism and 2 module width, it’s perfect for residential and commercial electrical distribution boards, providing essential protection against earth leakage and overcurrent.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 16A 6kA 240V 30mA | Type A | Trip-Free Mechanism | 2 Module Width | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHA9D61816
Alternatively Known As: 16A RCBO, Clipsal RCBO, Residual Current Circuit Breaker with Overcurrent, SCHA9D61816, 2 Module RCBO, 16A 30mA RCBO
Technical Specifications
- Rated current: 16A
- Breaking capacity: 6kA
- Rated voltage: 240V AC
- Residual current sensitivity: 30mA
- Type A RCBO
- 2 module width
- Trip-free mechanism
- Operating temperature: -5°C to +40°C
- IP20 (when installed in enclosure)
- Dimensions (H x L x W): 85mm x 75mm x 36mm
- Weight: 0.15 kg
Key Features
- Combined residual current device (RCD) and miniature circuit breaker (MCB) in one unit
- Rated current: 16A
- Breaking capacity: 6kA
- Rated voltage: 240V AC
- Residual current sensitivity: 30mA
- 2 module width for easy installation
- Provides protection against earth leakage, overload, and short circuit
- Trip-free mechanism ensures safety even if the toggle is held in ON position
Professional Installation Requirements
- Must be installed by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Residential and commercial electrical distribution boards
- Protection of final sub-circuits against earth leakage and overcurrent
- Suitable for lighting and power circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 61009.1 – Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses (RCBOs)
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty.
Available Now
The Clipsal RCBO 16A 6kA 240V 30mA 2M (SCHA9D61816) is available for immediate purchase. Ideal for residential and commercial circuit protection applications.
