RCBO 1P 4.5kA 30mA 10A | Compact Design | Pulset
Trade Discount 23%
RCBO with 10A rated current and 4.5kA breaking capacity—ideal for residential and commercial circuit protection. Built for safety, with low 30mA leakage current and compact design.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: A TYPE RCBO 1P 4.5KA 30mA 10AMP - RCBOLN45/1P10A
Brand: Pulset
SKU: RCBOLN45/1P10A
Alternatively Known As: Residual Current Breaker with Overcurrent Protection, RCBO
Technical Specifications
- Rated Current: 10A
- Voltage: 230V
- Tripping Sensitivity: 30mA
- Breaking Capacity: 4.5kA
- Dimensions (H x L x W): 100mm x 70mm x 90mm
- Weight: 0.5 kg
Key Features
- 1 Pole circuit breaker with low leakage current of 30mA
- 4.5kA short circuit breaking capacity
Professional Installation Requirements
- Installation by a qualified electrician is recommended for optimal performance and safety.
Applications
- Residential: Homes, apartments, general electrical installations
- Commercial: Offices, retail spaces requiring reliable circuit protection
Standards & Compliance
- Complies with AS/NZS 61009 for safety and performance standards.
Environmental Benefits
- Minimizes risks of electrical hazards, promoting safety and energy efficiency.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The A TYPE RCBO 1P 4.5KA 30mA 10AMP - RCBOLN45/1P10A is available now for immediate purchase. Ideal for circuit protection in residential and commercial electrical installations.
