RCBO 1P 6A 6kA 10mA Sensitivity Type A C Curve 2 Module MOD6 NHP

BRAND: NHP
SKU: MOD6RCBO20610A
$50.10 List price: $62.40
+ −
30 Days Return Electricians Unlock Trade Access
NHP MOD6 1-pole 6A RCBO features 6kA breaking capacity, 10mA Type A residual protection and C-curve tripping. Ideal for final subcircuit protection.
Technical Specifications
  • Rated Current: 6 A
  • Rated Voltage: 240 V
  • Frequency: 50/60 Hz
  • Trip Curve: C
  • Rated Impulse Withstand Voltage: 6 kV
  • Tripping Time: 40 ms
  • Electrical Life: 10,000 cycles
  • Mechanical Life: 20,000 cycles
  • Degree of Protection: IP20
  • Operating Temperature: -5 to 55 °C
  • Dimensions (H x L x W): 86mm x 76mm x 36mm
  • Weight: 0.25 kg
Key Features
  • 6kA short circuit breaking capacity
  • 10mA rated leakage current
  • C curve trip characteristic
  • DIN rail mounting for easy installation
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices and retail spaces
  • Industrial: Machinery and equipment protection
Standards & Compliance
  • Complies with AS/NZS 61009 for safety and performance standards.
Environmental Benefits
  • Designed to enhance electrical safety and reduce the risk of electrical fires.
Warranty Information

Standard warranty applies.

Available Now

The NHP MOD6 Residual Current Device is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.

Non-Returnable & Non-Cancellable

MOD6RCBO20610A-AU-RCBO-6kA-1P-and-N-36mm-Datasheet.pdf (MOD6RCBO20610A-AU-RCBO-6kA-1P-and-N-36mm-Datasheet.pdf, 436 Kb) [Download]
