RCBO 1P+N 10kA C-32A | 30mA A Class | Curve C Protection by Hager
RCBO 1P+N with 10kA breaking capacity and 30mA residual current—ideal for residential and commercial safety. Built for optimal protection with Curve C configuration and RoHS compliance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 1P+N 10kA C-32A 30mA A Class
Brand: Hager
SKU: ADA582T
Alternatively Known As: Residual Current Circuit Breaker, RCBO, Circuit Protection Device
Technical Specifications
- Rated insulation voltage: 500 V
- Rated operational voltage: 230 - 240 V
- Rated current: 32 A
- Rated residual operating current: 30 mA
- Operating temperature: -25 to 40 °C
- Endurance: 2000 electric cycles, 1000 mechanical operations
- Dimensions (H x L x W): 83mm x 68mm x 35mm
- Weight: 0.5 kg
Key Features
- 1P+N configuration with Curve C for optimal protection.
- Rated short-circuit breaking capacity of 10 kA.
- Residual current type A for enhanced safety.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- RoHS compliant, contributing to reduced environmental impact.
- Commitment to improving environmental performance by reducing carbon footprint.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager RCBO 1P+N 10kA C-32A 30mA A Class is available now for immediate purchase. Ideal for residential and commercial electrical safety.
