RCBO 1P+N 6KA 10A C Curve | 30MA Type AC | Compact Design
RCBO with 1P+N configuration, 6KA short circuit capacity, and 10A C curve—ideal for load centers and panelboards. Built for safety and reliability, with compact design and DIN rail mounting.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 1P+N 6KA 10A C Curve | 30MA Type AC | Compact Design
SKU: M6RCBS1030C
Alternatively Known As: Residual Current Breaker with Overcurrent Protection, RCBO 10A 30mA, Miniature Circuit Breaker with RCD, 1P+N RCBO
Technical Specifications
- Component Type: RCBO
- Busbar System: Fork (Top and Bottom)
- RCD Type: AC (AS/NZS 61008/61009 compliant)
- Rated Residual Making & Breaking Capacity (IΔm): 3000A
- Rated Current (In): 10A
- Rated Residual Operating Current (IΔn): 30mA
- Rated Short Circuit Capacity (Icn): 6kA
- Rated Frequency: 50Hz
- Relative Humidity Max: 95%
- IP Rating Inside: IP40
- IP Rating Outside: IP20
- Mounting: DIN Rail
- Number of Poles: 1
- Insulation Resistance: 1000 MΩ
- Electrical Service Life at Un, In: 10,000 operations
- Mechanical Service Life: 20,000 operations
- Calibration Temperature: 30°C
- Operating Temperature Range: -5°C to 55°C
- Storage Temperature Range: -25°C to 70°C
- Tightening Torque Nominal (Top and Bottom): 3 Nm
- Trip Curve: C
- Self Extinguish Degree (UL94): V-2
- Vibration Acceleration Max: 1.5 m/s²
- Rated Insulation Voltage (Ui): 500V
- Nominal Voltage AC (Un): 240V
- Service Voltage AC Max (Ubmax): 255V
- Service Voltage AC Min (Ubmin): 85V
- Wire/Conductor Size Max Bottom Rigid Cable: 25 mm²
- Wire/Conductor Size Max Top Rigid Cable: 16 mm²
- Isolator Application IEC 60947-2: Yes
- Dimensions (H x L x W): 86mm x 76mm x 18mm
- Weight: 0.125 kg
Key Features
- 1 Pole + Neutral RCBO with 6kA short circuit capacity
- C Curve trip characteristic for general use
- 30mA Type AC residual current protection
- Compact design suitable for DIN rail mounting
- Self-extinguishing V-2 rated material
- Rated insulation voltage of 500V
- Suitable for rigid cables up to 25 mm² bottom and 16 mm² top
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with electrical safety standards and correct operation.
Applications
- Residential electrical distribution boards
- Commercial panelboards and loadcenters
- Industrial electrical safety systems
Standards & Compliance
- AS/NZS 61009 – Residual Current Circuit Breakers with Overcurrent Protection (RCBOs)
Environmental Benefits
- Enhances electrical safety reducing risk of electrical fires and faults
- Compact design reduces material usage and waste
- Supports energy-efficient electrical installations by preventing faults
Warranty Information
Standard manufacturer warranty applies; typically 1-3 years depending on purchase terms.
Available Now
The NHP RCBO 1P+N 6KA 10A C Curve 30MA Type AC Compact is available for immediate purchase. Ideal for residential, commercial, and industrial electrical safety applications.
