RCBO 20A 30mA 1P C Curve | 10kA Breaking Capacity | Chassis Mount Design by Eltech
RCBO 20A with 30mA sensitivity and C Curve tripping—ideal for residential and commercial electrical systems. Built for secure installation, with a 10kA breaking capacity to enhance circuit protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 20A 30mA 1P C Curve 10kA Chassis Mount
Brand: Eltech
SKU: ODN1C2030AH
Alternatively Known As: RCBO 20 Amp 30mA Residual Current Breaker, 1 Pole RCBO, C Curve RCBO, 10kA RCBO
Technical Specifications
- Rated Current: 20A
- Residual Current: 30mA (Type A)
- Poles: 1 Pole
- Tripping Curve: C Curve
- Breaking Capacity: 10kA
- Mounting Type: Chassis Mount
- Dimensions (H x L x W): 85mm x 70mm x 18mm
- Weight: 0.2 kg
Key Features
- 20 Ampere rated current
- 30mA residual current sensitivity (Type A)
- C Curve tripping characteristic for general use
- 10kA short circuit breaking capacity
- Chassis mount design for secure installation
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
- Residential electrical distribution boards
- Commercial electrical panels
- Industrial power distribution systems requiring circuit protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Helps prevent electrical fires by detecting earth leakage currents
- Enhances energy safety and reduces risk of electrical hazards
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Eltech RCBO 20A 30mA 1P C Curve 10kA Chassis Mount is available for immediate purchase, ideal for enhancing circuit protection in residential, commercial, and industrial electrical systems.
