RCBO 25A 1 Pole + Neutral | 6kA Breaking Capacity | 30mA A Type | Eltech
RCBO 25A 1 pole + neutral with 6kA breaking capacity and 30mA A type sensitivity—ideal for residential and commercial electrical systems. Built for safety and reliability, it provides combined overcurrent and earth fault protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 25A 1 pole + Neutral 6kA 30mA – A type
Brand: Eltech
SKU: RCBO102530AS
Alternatively Known As: Residual Current Breaker with Overcurrent Protection, RCBO 25 Amp, 1P+N RCBO, 30mA A Type RCBO
Technical Specifications
- Rated current: 25A
- Residual current: 30mA (A type)
- Breaking capacity: 6kA
- Pole configuration: 1 pole + neutral
- Type: A (sensitive to AC and pulsating DC residual currents)
- Dimensions (H x L x W): 85mm x 70mm x 18mm
- Weight: 0.2 kg
Key Features
- Rated current: 25A
- Residual current rating: 30mA - A type
- Breaking capacity: 6kA
- 1 pole plus neutral configuration
- Provides combined overcurrent and earth fault protection
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
- Residential electrical distribution boards
- Commercial power distribution panels
- Industrial circuit protection systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Enhances electrical safety reducing risk of electrical fires and faults
- Supports energy-efficient electrical system protection
Warranty Information
Standard manufacturer warranty applies. Please refer to Eltech for specific warranty terms.
Available Now
The Eltech RCBO 25A 1 Pole + Neutral 6kA 30mA A Type is available for immediate purchase, ideal for enhancing circuit protection in residential, commercial, and industrial electrical systems.
