RCBO 25A 6KA 240V 30mA | Type A | 2 Module Width | by Clipsal
The RCBO 25A 6KA 240V 30mA is a Type A residual current circuit breaker that combines RCD and MCB functionalities in one compact unit. Ideal for residential, commercial, and industrial applications, it provides essential protection against earth leakage, overload, and short circuit faults. With a breaking capacity of 6kA and a 30mA sensitivity, this device ensures enhanced electrical safety and compliance with local regulations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 25A 6KA 240V 30mA | Type A | 2 Module Width | by Clipsal
Brand: Clipsal
SKU: SCHA9D61825
Alternatively Known As: 25A RCBO, Clipsal RCBO, Residual Current Circuit Breaker with Overcurrent, SCHA9D61825, 2 Module RCBO, 25A 30mA RCBO
Technical Specifications
- Rated current: 25A
- Breaking capacity: 6kA
- Rated voltage: 240V AC
- Residual current sensitivity: 30mA
- Type A RCBO
- 2 module width
- Operating frequency: 50Hz
- Trip curve: C
- IP20 (when installed in enclosure)
- Complies with IEC/EN 61009-1
- Dimensions (H x L x W): 85mm x 75mm x 36mm
- Weight: 0.25 kg
Key Features
- Combines residual current device (RCD) and miniature circuit breaker (MCB) in one unit
- Rated current: 25A
- Breaking capacity: 6kA
- Rated voltage: 240V AC
- Residual current sensitivity: 30mA
- 2 module width for easy installation
- Provides protection against earth leakage, overload, and short circuit faults
- Compact design for space-saving in switchboards
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Residential electrical distribution boards
- Commercial switchboards
- Industrial electrical panels
- Protection of lighting and power circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 61009.1 – Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses (RCBOs)
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal RCBO 25A 6kA 240V 30mA 2M (SCHA9D61825) is available for immediate purchase. Ideal for residential, commercial, and industrial electrical protection applications.
