RCBO 32A 10KA 110V 100mA | 4 Module Width | C Curve Tripping | by Clipsal
The RCBO 32A 10KA 110V 100mA is a reliable residual current circuit breaker designed for industrial and commercial applications. With a 4 module width and C curve tripping characteristic, it provides essential overload and earth leakage protection. Ideal for 110V installations, this device enhances electrical safety and minimizes downtime, making it a must-have for any electrical distribution board.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 32A 10KA 110V 100mA | 4 Module Width | C Curve Tripping | by Clipsal
Brand: Clipsal
SKU: SCHA9D19232
Alternatively Known As: 32A RCBO, Clipsal earth leakage breaker, 110V RCBO, SCHA9D19232, 4 module RCBO, Residual Current Circuit Breaker with Overcurrent Protection
Technical Specifications
- Rated current: 32A
- Breaking capacity: 10kA
- Rated voltage: 110V AC
- Earth leakage sensitivity: 100mA
- Tripping curve: C
- Number of poles: 2
- Module width: 4M
- Residual current device type: AC
- Conforms to IEC/EN 61009-1
- Dimensions (H x L x W): 85mm x 75mm x 72mm
- Weight: 0.45 kg
Key Features
- Combined residual current device and miniature circuit breaker (RCBO)
- Rated current: 32A
- Breaking capacity: 10kA
- Rated voltage: 110V AC
- Earth leakage sensitivity: 100mA
- 4 module width (4M)
- C curve tripping characteristic
- 2 pole (2P) configuration
- Provides both overload and earth leakage protection
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Industrial electrical distribution boards
- Commercial switchboards
- Protection of circuits in factories and warehouses
- Suitable for 110V installations requiring earth leakage protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Supports reliable power distribution, minimizing downtime and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal RCBO 32A 10KA 110V 100mA 4M (SCHA9D19232) is available for immediate purchase. Ideal for industrial and commercial electrical protection applications.
