RCBO 32A 3 Pole + Neutral | 10kA Breaking Capacity | 30mA Sensitivity | A Type by Eltech
RCBO 32A 3 pole + neutral with 10kA breaking capacity and 30mA sensitivity—ideal for residential and commercial power distribution. Built for safety compliance, it provides combined overcurrent and earth leakage protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 32A 3 pole + Neutral 10kA 30mA – A type
Brand: Eltech
SKU: RCBO303230AH
Alternatively Known As: Residual Current Breaker with Overcurrent Protection, 32A RCBO, 3 Pole RCBO, Earth Leakage Circuit Breaker
Technical Specifications
- Rated Current: 32A
- Poles: 3 pole + neutral
- Residual Current: 30mA (A type)
- Breaking Capacity: 10kA
- Type: A (sensitive to AC and pulsating DC residual currents)
- Dimensions (H x L x W): 85mm x 70mm x 54mm
- Weight: 0.3 kg
Key Features
- 32 Ampere rated current
- 30mA residual current trip sensitivity - A type
- 3 pole plus neutral configuration
- 10kA short circuit breaking capacity
- Provides combined overcurrent and earth leakage protection
Professional Installation Requirements
- Must be installed by a licensed electrician to ensure compliance with electrical safety standards and proper operation.
Applications
- Residential electrical distribution boards
- Commercial power distribution systems
- Industrial electrical panels requiring circuit protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Enhances electrical safety reducing risk of electrical fires and faults
- Helps prevent energy waste by quickly isolating faulty circuits
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Eltech RCBO 32A 3 Pole + Neutral 10kA 30mA – A Type is available now for immediate purchase. Ideal for enhancing safety in power distribution boards across residential, commercial, and industrial applications.
