RCBO 32A 6kA 240V 30mA | 2 Module Width | Earth Leakage Protection | by Clipsal
The RCBO 32A 6kA 240V 30mA is a reliable circuit protection device that combines an RCD and MCB in one unit, ensuring safety against overloads and earth leakage faults. Ideal for residential, commercial, and light industrial applications, this 2-module width device is designed for easy installation in standard distribution boards, providing peace of mind for electrical safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 32A 6kA 240V 30mA | 2 Module Width | Earth Leakage Protection | by Clipsal
Brand: Clipsal
SKU: SCHA9D61832
Alternatively Known As: 32A RCBO, Clipsal RCBO, Residual Current Circuit Breaker with Overcurrent, SCHA9D61832, 32A 6kA RCBO, Clipsal 2 Module RCBO
Technical Specifications
- Rated Current: 32A
- Breaking Capacity: 6kA
- Rated Voltage: 240V AC
- Earth Leakage Sensitivity: 30mA
- Number of Poles: 1P+N (Single Phase + Neutral)
- Modules: 2
- Frequency: 50Hz
- Trip Curve: C
- Mounting: DIN rail
- Standards: IEC/EN 61009-1
- Dimensions (H x L x W): 90mm x 75mm x 36mm
- Weight: 0.25 kg
Key Features
- Combines residual current device (RCD) and miniature circuit breaker (MCB) in one unit
- Rated at 32A, 6kA breaking capacity
- 30mA earth leakage protection
- 2 module width for easy installation in standard distribution boards
- 240V single phase operation
- Provides protection against overload, short circuit, and earth leakage faults
Professional Installation Requirements
- Must be installed by a licensed electrician in accordance with Australian wiring rules and standards.
Applications
- Residential: Circuit protection for homes
- Commercial: Offices, retail, and hospitality electrical distribution boards
- Industrial: Light industrial switchboards requiring RCD and MCB protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Long service life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal RCBO 32A 6kA 240V 30mA 2M (SCHA9D61832) is available for immediate purchase. Ideal for use in residential, commercial, and light industrial switchboards requiring reliable circuit and earth leakage protection.
