RCBO 45A 6kA 240V 30mA | 2 Module Width | Earth Leakage & Overload Protection | by Clipsal
The RCBO 45A 6kA 240V 30mA is designed for reliable circuit protection, combining a residual current device and miniature circuit breaker in one unit. Ideal for residential and commercial applications, it offers protection against earth leakage, overload, and short circuits. With a compact 2-module width, it's easy to install on DIN rails, ensuring safety and compliance with Australian standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 45A 6kA 240V 30mA | 2 Module Width | Earth Leakage & Overload Protection | by Clipsal
Brand: Clipsal
SKU: SCHA9D61845
Alternatively Known As: 45A RCBO, Clipsal RCBO, Residual Current Breaker with Overcurrent, SCHA9D61845, 2 Module RCBO, 45A 6kA RCBO
Technical Specifications
- Rated current: 45A
- Breaking capacity: 6kA
- Rated voltage: 240V AC
- Tripping sensitivity: 30mA
- Number of poles: 1P+N (Single phase + Neutral)
- Mounting: DIN rail
- Width: 2 modules
- Operating temperature: -5°C to +40°C
- IP20 protection rating
- Dimensions (H x L x W): 85mm x 75mm x 36mm
- Weight: 0.25 kg
Key Features
- Combines residual current device (RCD) and miniature circuit breaker (MCB) in one unit
- Rated current: 45A
- Breaking capacity: 6kA
- Voltage: 240V AC
- Tripping sensitivity: 30mA
- 2 module width for easy installation
- Provides protection against earth leakage, overload, and short circuit
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with Australian standards and local regulations.
Applications
- Residential: Circuit protection for homes
- Commercial: Offices, retail, and light industrial installations
- General: Suitable for use in switchboards requiring combined RCD and circuit breaker protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 61009 – Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses (RCBOs)
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal RCBO 45A 6kA 240V 30mA 2M (SCHA9D61845) is available for immediate purchase. Ideal for residential and commercial switchboard protection applications.
