RCBO 4P 10kA C-10A 100mA | High Breaking Capacity | IP20 Rated by Hager
RCBO with 4-pole design and 10kA breaking capacity—ideal for residential and commercial circuit protection. Built for safety, with 10A rated current and 100mA residual current, ensuring reliable performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 4P 10kA C-10A 100mA A
Brand: Hager
SKU: AEX410T
Alternatively Known As: Residual Current Circuit Breaker, RCBO, Circuit Protection Device
Technical Specifications
- Rated current: 10 A
- Rated residual operating current: 100 mA
- Rated service breaking capacity: 10 kA
- Voltage supply: 240 - 415 V
- Ingress Protection (IP) class: IP20
- Operating temperature: -25 to 40 °C
- Frequency: 50 Hz
- Connection cross-section: 1 - 16 mm² for flexible conductors, 1 - 25 mm² for solid conductors
- Dimensions (H x L x W): 84mm x 70mm x 71mm
- Weight: 0.5 kg
Key Features
- 4-pole design for comprehensive circuit protection.
- Rated current of 10 A with a residual operating current of 100 mA.
- High breaking capacity of 10 kA.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- RoHS compliant, contributing to reduced environmental impact.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager RCBO 4P 10kA C-10A 100mA A is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
