Trade Discount 22%
RCBO 4P 6kA C-40A | 100mA Residual Current | IP20 Rated by Hager
RCBO 4-pole with 40A current and 100mA residual current—ideal for residential and commercial safety. Built for comprehensive circuit protection, with high 6kA breaking capacity and IP20 rating.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 4P 6kA C-40A 100mA A
Brand: Hager
SKU: AEM440T
Alternatively Known As: Residual Current Circuit Breaker, RCBO, Modular Circuit Protection Device
Technical Specifications
- Rated current: 40 A
- Rated residual operating current: 100 mA
- Rated operational voltage: 240 - 415 V
- Rated insulation voltage: 500 V
- Dielectric strength: 2 kV
- Rated impulse withstand voltage: 4000 V
- Ingress Protection: IP20
- Operating temperature: -25 to 40 °C
- Total power loss under IN: 17.70 W
- Dimensions (H x L x W): 84mm x 70mm x 71mm
- Weight: 0.5 kg
Key Features
- 4-pole design for comprehensive circuit protection.
- Rated current of 40A and residual current of 100mA.
- High breaking capacity of 6kA.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- RoHS compliant, contributing to reduced environmental impact.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager RCBO 4P 6kA C-40A 100mA is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
