RCBO 4P 6kA C-6A 30mA | High Breaking Capacity | IP20 Rated by Hager
RCBO with 4-pole design and 6kA breaking capacity—ideal for residential, commercial, and light industrial applications. Built for comprehensive circuit protection, with 6A rated current and 30mA residual current.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCBO 4P 6kA C-6A 30mA A
Brand: Hager
SKU: ADM406T
Alternatively Known As: Residual Current Circuit Breaker, RCBO, Circuit Protection Device
Technical Specifications
- Rated current: 6 A
- Rated residual operating current: 30 mA
- Rated operational voltage: 240 - 415 V
- Rated insulation voltage: 500 V
- Dielectric strength: 2 kV
- Rated impulse withstand voltage: 4000 V
- Ingress Protection (IP) class: IP20
- Operating temperature: -25 to 40 °C
- Nominal tightening torque: 2 - 2 Nm
- Dimensions (H x L x W): 84mm x 70mm x 71mm
- Weight: 0.5 kg
Key Features
- 4-pole design for comprehensive circuit protection.
- Rated current of 6A with a residual current of 30mA.
- High breaking capacity of 6kA.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Light industrial applications requiring circuit protection
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- RoHS compliant, contributing to reduced environmental impact.
- Designed to improve energy efficiency and reduce carbon footprint.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager RCBO 4P 6kA C-6A 30mA A is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
