RCBO Chassis Mount Electromagnetic 3P+N 10kA 415V AC 63A C Curve | Type A | by Connected Switchgear
The RCBO Chassis Mount Electromagnetic 3P+N is designed for robust electrical protection, featuring a 10kA breaking capacity and a 30mA residual current rating. Ideal for industrial and commercial applications, this device ensures safety against earth leakage and overcurrent, complying with AS/NZS 61009.1 standards for reliable performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Residual Current Breaker with Overcurrent Protection, Electromagnetic RCBO, 3P+N RCBO, Type A RCBO
Technical Specifications
- Rated Current: 63A
- Rated Voltage: 415V AC
- Pole Configuration: 3P+N
- Breaking Capacity: 10kA
- Tripping Curve: C Curve
- Residual Current Rating: 30mA
- Type: A
- Mounting: Chassis Mount
- Standard Compliance: AS/NZS 61009.1
- Dimensions (H x L x W): 80mm x 70mm x 90mm
- Weight: 1.5 kg
Key Features
- Electromagnetic residual current device with overcurrent protection
- Chassis mount design for secure installation
- 10kA rated breaking capacity suitable for industrial and commercial use
- Protection for both active and neutral conductors
- Complies with AS/NZS 61009.1 standard
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with safety standards and proper operation.
Applications
- Industrial electrical systems requiring earth leakage protection
- Commercial electrical installations with overload and short circuit protection
- Electrical panels needing combined residual current and overcurrent protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enhances electrical safety reducing risk of electrical fires and faults
- Supports energy efficiency by preventing electrical faults and downtime
Warranty Information
Standard 1 year warranty against manufacturing defects.
Available Now
The Connected Switchgear RCBO Chassis Mount Electromagnetic 3P+N 10kA 415V AC 63A C Curve 30mA TYPE A is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
