RCBO Chassis Mount Electromagnetic 3P+N 6kA 415V AC 40A C Curve 30mA | by Connected Switchgear
The RCBO Chassis Mount Electromagnetic 3P+N is designed for reliable electrical protection, featuring a 6kA breaking capacity and a 30mA residual current rating. Ideal for industrial and commercial applications, this device safeguards against earth leakage, overload, and short circuits, ensuring safety and compliance with AS/NZS 61009.1 standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Residual Current Breaker with Overcurrent Protection, Electromagnetic RCBO, 3P+N RCBO, Type A RCBO
Technical Specifications
- Rated Current: 40A
- Rated Voltage: 415V AC
- Pole Configuration: 3P+N
- Breaking Capacity: 6kA
- Trip Curve: C Curve
- Residual Current Rating: 30mA
- Type: A (sensitive to AC and pulsating DC residual currents)
- Compliance: AS/NZS 61009.1
- Dimensions (H x L x W): 85mm x 70mm x 90mm
- Weight: 1.2 kg
Key Features
- Electromagnetic residual current device with over current protection
- 6kA rated breaking capacity for high fault current interruption
- C Curve trip characteristic suitable for general applications
- Protection against earth leakage, overload, and short circuit
- Designed for chassis mount installation
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with safety standards and proper operation.
Applications
- Industrial electrical distribution systems
- Commercial electrical installations requiring earth leakage protection
- Protection of active and neutral conductors in electrical circuits
Standards & Compliance
- Complies with AS/NZS 61009.1 – Residual current operated circuit-breakers with integral overcurrent protection for household and similar uses
Environmental Benefits
- Enhances electrical safety reducing risk of electrical fires and faults
- Supports energy efficiency by preventing electrical faults and downtime
Warranty Information
3 years warranty against manufacturing defects.
Available Now
The Connected Switchgear RCBO Chassis Mount Electromagnetic 3P+N 6kA 415V AC 40A C Curve 30mA TYPE A is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
