RCD Horizontal 20A 10mA White | High-Sensitivity Trip | Single Pole Design | by Clipsal
The RCD Horizontal 20A 10mA White is a reliable residual current device designed for enhanced electrical safety. With a high-sensitivity trip threshold of 10mA, it provides optimal protection for residential and commercial power circuits. Its sleek white finish and single pole design make it a modern choice for any indoor application, ensuring compliance with Australian safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCD Horizontal 20A 10mA White | High-Sensitivity Trip | Single Pole Design | by Clipsal
Brand: Clipsal
SKU: MEDML2031RCD10WE
Alternatively Known As: Clipsal RCD 20A 10mA, Residual Current Device 20A, MEDML2031RCD10WE, Clipsal Safety Switch, Clipsal Horizontal RCD
Technical Specifications
- Rated Current: 20A
- Sensitivity: 10mA
- Type: Residual Current Device (RCD)
- Configuration: Horizontal, single pole
- Colour: White
- Test Button: Yes
- Voltage: 230-240V AC
- Frequency: 50Hz
- Mounting: Flush or surface mount
- Dimensions (H x L x W): 120mm x 60mm x 75mm
- Weight: 0.25 kg
Key Features
- Horizontal RCD (Residual Current Device) with 20A current rating
- 10mA high-sensitivity trip threshold for enhanced personal protection
- Single pole, single module design
- White finish for modern aesthetics
- Test button for regular safety checks
- Complies with Australian safety standards
Professional Installation Requirements
- Installation must be carried out by a licensed electrician to ensure compliance with Australian electrical safety standards.
Applications
- Residential: Protection of power circuits in homes
- Commercial: Offices, retail, and hospitality environments
- General: Any indoor location requiring RCD protection for safety compliance
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3190 – Approval and test specification – Residual current devices (current-operated earth-leakage devices)
Environmental Benefits
- Enhances electrical safety, reducing risk of electrical fires and accidents
- Long operational life reduces replacement frequency and waste
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Clipsal RCD Horizontal 20A 10mA White MEDML2031RCD10WE is available for immediate purchase. Ideal for residential and commercial electrical safety applications.
