RCD Protected Switched Socket Outlet | 500V 20A | IP66 3 Pole | Grey by Clipsal
RCD protected switched socket outlet with 500V 20A capacity and IP66 rating—ideal for industrial and commercial use. Built for enhanced safety and durability, with vertical surface mounting and 5 round pin design.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Clipsal - 56 Series, RCD Protected Switched Socket Outlet, 500V, 20A, 5 Round PIN, IP66, 3 Pole - Grey
Brand: Clipsal
SKU: 56C520RC-GY
Alternatively Known As: RCD Socket Outlet, 5 Round Pin Socket, IP66 Socket
Technical Specifications
- Rated current: 20A
- Rated operational voltage: 500V AC 50Hz
- Number of poles: 5
- Control type: Push-button
- Number of gangs: 3
- Connections: Screw terminals for cables 1.5-16 mm²
- Earth-leakage protection class: Class A
- Material: Polycarbonate
- Dimensions (H x L x W): 294mm x 110mm x 101mm
- Weight: 1.64 kg
Key Features
- RCD protected for enhanced safety.
- IP66 rated for dust and water resistance.
- Designed for vertical surface mounting.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Small commercial, industry, utility
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Compliant with RoHS directives, ensuring reduced environmental impact.
Warranty Information
Standard warranty applies.
Available Now
The Clipsal 56 Series RCD Protected Switched Socket Outlet is available now for immediate purchase. Ideal for industrial and commercial applications.
