RCD Relay 10mA 10MS 240V | Fast Tripping Time | DIN Rail Mountable | by Clipsal
The RCD Relay 10mA 10MS 240V is designed for high-sensitivity earth leakage detection, making it ideal for medical facilities and commercial buildings. With a rapid tripping time of just 10 milliseconds, this relay-based device ensures enhanced electrical safety. Its compact DIN rail mountable design allows for easy installation in switchboards, providing critical protection for sensitive equipment and personnel.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCD Relay 10mA 10MS 240V | Fast Tripping Time | DIN Rail Mountable | by Clipsal
Brand: Clipsal
SKU: MEDE03/10/10
Alternatively Known As: 10mA RCD Relay, Medical RCD Relay, Clipsal Earth Leakage Relay, Residual Current Device Relay, MEDE03/10/10
Technical Specifications
- Rated voltage: 240V AC
- Sensitivity: 10mA
- Tripping time: 10 milliseconds
- Mounting: DIN rail
- Type: Relay-based RCD
- Operating frequency: 50Hz
- Standards: Complies with AS/NZS 3190
- Dimensions (H x L x W): 90mm x 70mm x 36mm
- Weight: 0.25 kg
Key Features
- High sensitivity 10mA earth leakage detection for critical safety applications
- Fast tripping time of 10 milliseconds for rapid response
- Operates at 240V AC for compatibility with standard Australian electrical systems
- Relay-based design for integration with control and monitoring systems
- Compact DIN rail mountable for easy installation in switchboards
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Medical facilities: patient areas, operating theatres
- Laboratories: sensitive equipment protection
- Commercial buildings: enhanced electrical safety
- Industrial sites: machinery and personnel protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of electrical fires and accidents
- Supports compliance with safety standards in sensitive environments
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal RCD Relay 10mA 10MS 240V (MEDE03/10/10) is available for immediate purchase. Ideal for medical, laboratory, and commercial applications requiring high-sensitivity earth leakage protection.
