Recordable 4-3 Annunciator Ness

BRAND: Ness
SKU: 101-264
$203.00 List price: $270.70
+ −
30 Days Return Electricians Unlock Trade Access
Ness recordable annunciator provides recorded voice announcements for alarm systems. Ideal for alarm and security installs.

Alternatively Known As: Ness 101-264, ELK-120 Recordable Voice and Siren Driver, Recordable Voice Module, Alarm Voice Annunciator

Technical Specifications
  • Channels: Four configurable channels
  • Channel Configuration: Two siren and two recordable voice channels, or four recordable voice channels
  • Recording Capacity: Eight minutes total, divisible between voice channels
  • Operating Voltage: 11–14 V DC
  • Current Draw: 0.25–1.8 A, depending on volume and speaker load
  • Trigger Input: 9–14 V DC at 30 mA
  • Maximum Sound Level: 122 dB at 1 metre
  • Maximum Speaker Load: 4 ohms
  • Amplifier Output: 24 W
  • Memory: Non-volatile recording storage
  • Recording Method: Built-in condenser microphone or WAV file download via compatible PC interface
  • Playback Modes: One-shot or continuous
  • Siren Tones: Classic yelp, temporal coded horn and pulsing industrial horn
  • Dimensions (H x L x W): 32mm x 127mm x 76mm
  • Weight: 0.2 kg
Key Features
  • Four configurable voice and siren channels
  • Up to eight minutes of total recordable voice capacity
  • Voice recordings retained in non-volatile memory
  • Built-in microphone for direct recording
  • Compatible with WAV file transfer using the Ness 101-262 computer sound card interface
  • Adjustable speaker volume and current draw
  • Line-level output for paging systems and amplifiers
  • Momentary trigger support for voice channels
  • Suitable for alarm, security and access-control warning announcements
Professional Installation Requirements
  • Installation and connection should be performed by a suitably qualified security or electrical technician. The module operates from extra-low-voltage DC but requires connection to alarm outputs, speakers and, where used, external audio equipment.
Applications
  • Intruder alarm voice announcements
  • Security and access-control warnings
  • Commercial and industrial alarm systems
  • Emergency or evacuation messaging where the wider system is designed for that purpose
  • Paging and public-address integrations
  • Custom voice, music and alert playback systems
Standards & Compliance
  • Applicable to intruder alarm system design, installation, commissioning and maintenance under AS/NZS 2201.1:2007; product-specific Australian certification was not identified in the available manufacturer documentation.
Environmental Benefits
  • Non-volatile memory allows recordings to be reused without consumable media
  • Low-voltage DC operation avoids direct mains connection at the module
  • Reusable electronic construction can reduce replacement waste over the service life of the alarm system
  • Ness publishes RoHS compliance information for its product range
Warranty Information

Ness Corporation manufactured or supplied products are covered by a three-year warranty from the date of purchase, subject to Ness warranty terms and exclusions.

Available Now

Available through Ness Corporation and authorised Australian security and electrical distributors.
