Rectangular PNP Proximity Sensor | IP68 Enclosure | 75mm Sensing Range | 250Hz Switching Frequency | by SICK
The Rectangular PNP Proximity Sensor is designed for industrial automation, featuring an IP68 enclosure and a sensing range of 75 mm. With a robust switching frequency of 250 Hz and magnetic-field resistance, this sensor is perfect for welding applications and environments where reliability is crucial.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 1.8 V
- Hysteresis: 3% to 15%
- Reproducibility: ≤ 2%
- Temperature drift of sensing range: ≤ ±10%
- Continuous current: ≤ 200 mA
- No load current: ≤ 15 mA
- Off-state current: ≤ 0.1 mA
- Magnetic field strength tolerance: ≤ 100 mT
- Shock and vibration resistance: 30 g, 11 ms / 10 to 55 Hz, 1 mm
- Ambient operating temperature: –25 °C to +70 °C
- Housing and sensing face material: Plastic, PBT
- Tightening torque max: 4 Nm
- Protection class: II
- Connection type: Male connector M12, 4-pin
- Switching output: PNP complementary
- Switching frequency: 250 Hz
- Enclosure rating: IP68
- MTTFD: 139 years
- Mission time: 20 years
- Dimensions (H x L x W): 40mm x 114mm x 80mm
- Weight: 0.2 kg
Key Features
- Rectangular housing with IP68 enclosure rating
- Non-flush installation type
- Sensing range of 75 mm with safe sensing range of 60.7 mm
- Switching frequency of 250 Hz
- PNP complementary switching output
- Magnetic-field-resistant with reduction factor 1
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Short-circuit protection included
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure correct wiring and mounting according to manufacturer guidelines.
Applications
- Industrial automation sensing
- Welding range detection
- Magnetic-field-resistant environments
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Energy-efficient operation with low current consumption
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK for detailed warranty terms.
Available Now
The SICK IQR80-75NPPKC0S sensor is available for immediate purchase, ideal for industrial automation and welding applications requiring reliable non-flush sensing.
