Rectangular Proximity Sensor | 5 mm Sensing Range | IP67 Rated | NPN Normally Closed | by SICK
The Rectangular Proximity Sensor is designed for precise object detection with a sensing range of 5 mm and a safe sensing range of 4.05 mm. Ideal for industrial automation and safety monitoring, this non-flush installation sensor features a high switching frequency of 1,000 Hz and an IP67 rated enclosure for dust and water protection, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Housing: Rectangular plastic
- Sensing range Sn: 5 mm
- Safe sensing range Sa: 4.05 mm
- Installation type: Non-flush
- Switching frequency: 1,000 Hz
- Connection type: Cable, 3-wire, 2 m
- Switching output: NPN, Normally Closed (NC)
- Electrical wiring: DC 3-wire
- Enclosure rating: IP67
- Supply voltage: 10 V DC to 30 V DC
- Ripple: ≤ 10%
- Voltage drop: ≤ 2 V
- Time delay before availability: ≤ 100 ms
- Hysteresis: 5% to 15%
- Reproducibility: ≤ 2%
- Temperature drift: ± 10%
- EMC: According to EN 60947-5-2
- Continuous current Ia: ≤ 200 mA
- No load current: 10 mA
- Cable material: PVC
- Short-circuit protection: Yes
- Power-up pulse protection: Yes
- Ambient operating temperature: -25 °C to +75 °C
- Tightening torque max: 0.9 Nm
- Dimensions (H x L x W): 17mm x 29.5mm x 17mm
- Weight: 0.1 kg
Key Features
- Rectangular housing with compact dimensions of 17 mm x 17 mm x 29.5 mm
- Sensing range of 5 mm with safe sensing range of 4.05 mm
- Non-flush installation type
- High switching frequency of 1,000 Hz
- NPN normally closed switching output
- Cable connection type with 3-wire, 2 m length
- IP67 rated enclosure for dust and water protection
- Short-circuit and power-up pulse protection included
- Wide supply voltage range from 10 V DC to 30 V DC
- Operating temperature range from -25 °C to +75 °C
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper wiring and compliance with safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in machinery
- Non-flush mounting sensing applications
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable IP67 housing reduces need for frequent replacements, minimizing waste
- Low power consumption with efficient DC 3-wire electrical wiring
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK IQE17-05NNOKW2S proximity sensor is available for immediate purchase, ideal for industrial automation and safety monitoring applications.
