Trade Discount 33%
Red Push Button Switch | 20A 250V | DIN Rail Mount by Clipsal
Red push button switch with 20A current and 250V voltage—ideal for small commercial and residential circuits. Built for easy installation on DIN rail, with staggered terminals for simplified connection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Acti9, Single push-button, 1NC red
Brand: Clipsal
SKU: A9E18031
Alternatively Known As: Acti9 Push Button, Modular Push Button, Red Push Button Switch
Technical Specifications
- Rated operational current: 20 A
- Rated operational voltage: 250 V AC
- Electrical durability: AC-22: 30000 cycles at AC 50/60 Hz
- Mounting mode: Fixed on 35 mm symmetrical DIN rail
- Relative humidity: 95% at 55 °C
- Ambient air temperature for operation: -35 to 70 °C
- Ambient air temperature for storage: -40 to 80 °C
- Dimensions (H x L x W): 82mm x 71.5mm x 18mm
- Weight: 0.04 kg
Key Features
- Single normally closed (NC) contact
- Staggered terminals for simplified connection
- Tightening torque of 1 N.m
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Small commercial and residential electrical circuits
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Complies with IEC 60669-1 and IEC 60947-5-1 standards.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal Acti9 Single Push-Button 1NC Red is available now for immediate purchase. Ideal for small commercial and residential electrical applications.
