'Remote Emergency Enclosure 40W 1050mA 3Ah 6-60V Haneco'

BRAND: Haneco
SKU: EMLED-2.4W-3H-60V 40PL
$198.30 List price: $264.30
+ −
30 Days Return Electricians Unlock Trade Access
'Haneco remote emergency enclosure features 40W capacity, 1050mA output and 3Ah 6-60V battery backup. Ideal for emergency lighting conversions.'

Alternatively Known As: Haneco EMLED-2.4W-3H-60V 40PL, Remote Emergency Lighting Enclosure, LED Panel Emergency Kit

Technical Specifications
  • Product Code: EMLED-2.4W-3H-60V 40PL
  • SAP Code: 2000590
  • Input Voltage: 220–240V AC
  • Input Frequency: 50/60Hz
  • Output Current: 1050mA
  • Output Voltage: 13–38V
  • Emergency LED Voltage Range: 6–60V
  • Emergency LED Power: 2.4W
  • Input Power: 4W
  • Input Current: 40mA
  • Power Factor: 0.95 driver power factor; 0.5C emergency inverter power factor
  • Recharge Time: 20 hours
  • Charge Current: 200mA
  • Battery Capacity: 3Ah
  • Operating Temperature: 0°C to 50°C
  • Maximum Case Temperature: 70°C
  • Compatible Panels: Haneco Galaxy0312 and Galaxy0606
  • Enclosure Material: Galvanised steel
  • Installation Cable: Status indicator/test switch plate with 470mm cable
  • Dimensions (H x L x W): 36mm x 340mm x 90mm
  • Weight: 0.8 kg
Key Features
  • Remote emergency enclosure for converting compatible LED panels to emergency operation
  • 40W-rated driver system with 1050mA output
  • Supports emergency LED loads across a 6–60V range
  • 3Ah rechargeable battery backup
  • Integrated LED emergency inverter and driver
  • Power factor up to 0.95 for the supplied LED driver
  • Includes status indicator and test switch connection
  • Suitable for indoor use in compatible commercial panel-lighting applications
Professional Installation Requirements
  • Installation must be completed by a qualified and licensed electrician. Isolate the mains supply before installation or maintenance and install the emergency lighting system in accordance with applicable wiring and emergency-lighting requirements.
Applications
  • Emergency conversion of compatible Haneco LED panel luminaires
  • Showrooms and offices
  • Boardrooms and meeting rooms
  • Retail spaces and hotel common areas
  • Storage rooms and manufacturing facilities
  • Medical and commercial indoor environments
Standards & Compliance
  • AS/NZS 2293.1 – emergency lighting system design, installation and operation
  • AS/NZS 2293.3:2018 – emergency luminaires and exit signs
  • AS/NZS 3000:2018 – electrical installations and wiring rules
Environmental Benefits
  • Rechargeable battery system reduces reliance on disposable batteries
  • LED emergency operation can reduce energy consumption compared with conventional emergency-lighting sources
  • Galvanised steel enclosure is durable and recyclable at end of service life
  • Designed for conversion and continued use of compatible LED panels, potentially reducing replacement of complete luminaires
Warranty Information

1-year warranty for this specific Haneco remote emergency enclosure. Haneco’s general lighting warranty may vary by product, but the product page specifies one year for this model.

Available Now

Available through Haneco and authorised Australian electrical and lighting distributors.
