Residual Current Breaker RCBO 3 Pole 50A | 10kA D Curve | 100mA Type A by NHP
Residual current breaker with 3 pole configuration and 50A rated current—ideal for residential and commercial safety. Built for high inrush current applications, with 100mA leakage and DIN rail mounting.
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Residual Current Breaker RCBO 10kA 3 Pole 50A D Curve 100mA Type A (Longbody)
Brand: NHP
SKU: DTRTNN50100AD
Alternatively Known As: Residual Current Breaker, RCBO, Earth Leakage Circuit Breaker
- Rated Current: 50 A
- Rated Voltage: 415 V
- Rated Leakage Current: 100 mA
- Frequency: 50/60 Hz
- Rated Short Circuit Breaking Capacity: 10 kA
- Voltage Type: AC
- Trip Curve: D
- Rated Impulse Withstand Voltage: 4 kV
- Tripping Time: 300 ms
- Rated Insulation Voltage: 500 V
- Degree of Protection: IP40
- Electrical Life: 10,000 cycles
- Mechanical Life: 20,000 cycles
- Operating Temperature: -5 to 55 °C
- Dimensions (H x L x W): 117.5mm x 77.1mm x 54mm
- Weight: 0.49 kg
- 3 Pole configuration for three-phase systems.
- Rated current of 50A and leakage current of 100mA.
- Trip curve D for high inrush current applications.
- DIN rail mounting for easy installation.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
- Complies with AS/NZS 61009 for residual current devices.
- Enhances electrical safety, reducing the risk of electrical fires and accidents.
1 year warranty against manufacturing defects.
The NHP DIN-T Residual Current Breaker RCBO 10kA 3 Pole 50A D Curve 100mA Type A (Longbody) is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
