Residual Current Circuit Breaker 1P+N | 6kA C-40A 30mA | IP2X by Hager

BRAND: :hager
SKU: ADA940T
$41.90 List price: $53.60
+
Residual current circuit breaker with 1P+N configuration, 6kA breaking capacity, and 40A rated current—ideal for residential and commercial electrical protection. Built for safety, with IP2X ingress protection and energy efficiency.

Product Name/Title: RCB0 1P+N 6kA C-40A 30mA A Class

Brand: Hager

SKU: ADA940T

Alternatively Known As: Residual Current Circuit Breaker, RCBO, Circuit Protection Device

Technical Specifications
  • Rated current: 40A
  • Rated residual operating current: 30mA
  • Rated short-circuit breaking capacity: 6kA
  • Ingress Protection (IP) class: IP2X
  • Rated insulation voltage: 500V
  • Rated operational voltage: 230-240V
  • Operating temperature: -25 to 40°C
  • Endurance: 2000 electric cycles, 1000 mechanical operations
  • Dimensions (H x L x W): 83mm x 68mm x 35mm
  • Weight: 0.5 kg
Key Features
  • 1P+N configuration for single-phase applications.
  • Rated current of 40A and residual current of 30mA.
  • High breaking capacity of 6kA.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices and retail spaces
  • General: Any electrical installation requiring residual current protection
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
  • RoHS compliant, contributing to reduced environmental impact.
  • Designed to improve energy efficiency and reduce carbon footprint.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager RCB0 1P+N 6kA C-40A 30mA A Class is available now for immediate purchase. Ideal for residential and commercial electrical protection.
