Residual Current Circuit Breaker 3P+N | 100A 100mA | DIN Rail Mount by NHP
Residual current circuit breaker with 3 pole and neutral design, 100A rated current, and 100mA leakage current—ideal for residential and commercial safety. Built for easy installation with DIN rail mounting, enhancing electrical safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Residual Current Circuit Breaker RCCB 3Pole and Neutral 100A 100mA Type A ABB Brand F204A
Brand: NHP
SKU: DSRCD4100100A
Alternatively Known As: RCCB, Residual Current Circuit Breaker, RCD, Type A RCCB
Technical Specifications
- Number of Poles: 4
- Voltage Type: AC
- Frequency: 50/60 Hz
- Rated Current: 100 A
- Leakage Current Type: A
- Rated Leakage Current: 100 mA
- Min Service Voltage: 205 V
- Max Rated Operation Voltage: 455 V
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 8 kV
- Rated Fault Current: 10000 A
- Short Circuit Breaking Capacity: 1 kA
- Degree of Protection: IP20
- Operating Temperature: 55 °C
- Ambient Temperature During Operating: -25-55 °C
- Storage Temperature: 70 °C
- Pollution Degree: 2
- Dimensions (H x L x W): 86mm x 76mm x 72mm
- Weight: 0.37 kg
Key Features
- 3 Pole and Neutral design for enhanced safety.
- Rated current of 100A and leakage current of 100mA.
- DIN rail mounting for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical safety standards.
Environmental Benefits
- Enhances electrical safety, reducing the risk of electrical fires and accidents.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The NHP DIN-T Residual Current Circuit Breaker RCCB 3Pole and Neutral 100A 100mA Type A is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
